SENKO Sampling Type Fixed Gas Detector SI-H100

SENKO Sampling Type Fixed Gas Detector SI-H100

Key Features:

  • Wide Gas Detection Range: Detects a broad spectrum of gases, including toxic, flammable, and oxygen gases.
  • Integrated Sampling Pump: Features an extractive pump system with a 2-year lifespan, capable of sampling gas from distances up to 30 meters. The pump ensures continuous and reliable gas sampling.

  • Smart Sensor Cartridge: Each sensor cartridge is pre-calibrated and includes onboard diagnostics, simplifying maintenance and ensuring accurate readings.

  • User-Friendly Interface: Equipped with a large, bright graphic LCD that displays gas concentrations, flow rates, alarm statuses, and device diagnostics using intuitive icons.

  • Multiple Communication Options:

    • 4–20mA analog output

    • RS-485 and Modbus/TCP Ethernet for integration with control and alarm systems

    • Ethernet (PoE) for power and data transmission over a single cable

  • Alarm and Relay Outputs: Includes three built-in relays for primary alarm, secondary alarm, and fault conditions, with configurable NO/NC contacts.

  • Optional Pyrolyzer Module: For detecting gases that cannot be directly sensed, such as NF₃, the SI-H100 can be equipped with an optional pyrolyzer module that thermally decomposes the gas into detectable components.

  • Firmware Updates: Supports remote firmware updates via the web, ensuring the device remains up-to-date with the latest features and improvements.

Add to quote
Categories: , Brand:

SENKO SI-H100 measures sample gas by sensor cartridge in the case upon suction remotely on a real time basis constantly. The monitor points up to 100 feet (30 meters) away and shows alarm of dangerous concentration, fault situation, and so on, upon attaching on the wall. SI-H100 assists to prevent or control a variety of gas related accidents including toxic, flammable gases in a plant providing reliable sensor technology.

Pyrolyzer option can be installed  underneath  the standard SI-H100. For detection and measurement through thermal decomposition in case of substances that do not have a gas sensor that can be generally detected, such as NF3. Having remotely firmware update support, the SI-H100 delivers exceptional flexibility, safety, and reliability for advanced gas monitoring applications.
